Protect your living spaces from condensation and minimise up to 95% of radiant heat loss or gain; you only need one product for both.

Reflective Radiant Barriers For Use In Roofs, Walls & Floors…

The highly reflective foil surface acts as a barrier to reflect radiant heat rather than absorb it, like traditional insulation types. Radiant Barriers minimise solar heat gain and overheating during summer and help retain heat inside your property during winter. This means Radiant Barriers are the perfect solution to reduce your dependence on heating and cooling systems, saving you money on energy bills and preventing structural damage from condensation.



A certified 2-in-1 product, providing high-performing radiant barrier, and a vapour control layer—all within a single product.


Meet or exceed project requirements, whether used on its own or in hybrid solutions. Rigorous testing ensures compliance with the latest building regulations.


Reflects up to 95% of radiant heat.


Multifunctional,  lightweight and easy to install design that requires no specialist tools.


New build, retrofit, timber-frame and DIY projects to achieve maximum performance, while maintaining a slim profile.


How SuperFOIL SFTV FR Benefits You

SFTV FR is a true 2-in-1 designed product, providing a reflective radiant barrier in addition to a vapour control layer, outshining traditional insulation solutions when used in place of a standard vapour membrane. The product has been rigorously tested and certified to achieve almost three times the performance of a standard vapour control layer. This means that the high vapour resistance prevents warm air or water vapour from penetrating through the wall, significantly reducing the risk of condensation, mould, and subsequent structural damage to your property.

The highly reflective surface of SFTV FR allows it to act as a radiant barrier. By reflecting radiant heat, SFTV FR minimises solar gain and overheating in summer, keeping your home cool in the summer and retaining heat inside the property during winter for warmth. With the prevention of condensation and mould, a clean, thermally efficient  and comfortable indoor environment is also guaranteed year-round.


Due to their highly reflective properties, SuperFOIL SFTV FR can be applied across roofs, walls, and floors in new build, retrofit, and extension projects, whether domestic or commercial. The thin, easy-to-install and clever design facilitates the application and ensures tailored solutions for every project, either in single or duet setups, with minimal wastage and no unnecessary cleaning up after installation. This also eliminates your need to integrate any additional vapour control products to protect your property.

image image image

Technical Information

Technical Information


Specification Value
Product SFTV FR
Core Performance N/A
Roof Performance* 0.45 R Value
Wall Performance* 0.66 R Value
Floor Performance* 1.31 R Value
Emittance 0.05

*Core value + 2 air spaces / EN 16012

Specification Value
Thickness <1mm
Length 25/50m
Width 1m
Coverage 25/50m²
Weight 4/8kg

*Core value + 2 air spaces / EN 16012

Specification Value
Reaction To Fire (Euroclass) Class E

*Core value + 2 air spaces / EN 16012

Specification Value
Water Vapour Resistance 2500MNs/g
Resistance To Water Penetration W1
Tensile Properties (Length) 757N/50mm
Tensile Properties (Width) 726N/50mm
Resistance to Tearing (Length) 179N
Resistance to Tearing (Width) 453N
Elongation (Length) 15% /17 %
Elongation (Width) 14% / 16%
Flexibility at Low Temp. -40°C

*Core value + 2 air spaces / EN 16012
