SuperFOIL SF19FR

Quality-assured multifoil solutions for exceptional fire protection, insulation, and peace of mind.

High-performance And Fire-rated Multifoils For Use In Roofs, Walls, And Floors…

Engineered to withstand high temperatures, SF19FR offers protection for your property and enhances the comfort of your living spaces. With its unique multifoil features and state-of-the-art design, the SuperFOIL FR range stands out as the best and most innovative solution for creating safer, energy-efficient, and comfortable buildings all year round.

SuperFOIL SF19FR

3 IN 1 DESIGN

A certified 3-in-1 product, providing high-performing insulation, vapour control layer (VCL), and a radiant barrier—all within a single product.

ACHIEVE BUILDING COMPLIANCE

Meet or exceed project requirements, whether used on its own or in hybrid solutions. Rigorous testing ensures compliance with the latest building regulations.

EASY TO INSTALL

Multifunctional,  lightweight and easy to install design that requires no specialist tools.

SUSTAINABLE

Each product is manufactured from up to 40% recycled plastic content and is fully recyclable at the end of its 50+ year lifespan.

IDEAL FOR USE IN

New build, retrofit, timber-frame and DIY projects to achieve maximum performance, while maintaining a slim profile.

CLAIM YOUR FREE SAMPLE PACK

How SuperFOIL SF19FR Benefits You

SF19FR is designed to endure high temperatures without emitting toxic smoke, safeguarding the structural integrity of your buildings during a fire while preventing the spread of flames.

The FR range has undergone rigorous testing and received British Standard (BS 476) certification for Class 0 fire propagation and Class 1 spread of flame. With ‘Class 0’ certification, SF19FR prevents flame spread and limits heat release in the event of a fire. In terms of ‘Class 1’ performance, the FR range effectively protects your surfaces from the spread of flame.

The SuperFOIL FR range delivers the same excellent U-values as our standard Multifoil range, ensuring you receive high-performing insulation, a vapour control layer, radiant barrier, and superior fire protection all in one product. Choose SuperFOIL SF19FR for insulation that doesn’t compromise on safety or efficiency. It’s the best of both worlds.

Applications

Compared to many traditional insulation types, SuperFOIL SF19FR’s ease of installation, flexibility and multifunctional design minimise product wastage and installation time. Offering excellent value for money, our fire rated insulation is perfect for new builds, renovations, and extensions. It is versatile enough to be used in both domestic and commercial projects, regardless of the project’s size and scale. This means you don’t need to purchase additional vapour control and fire-rated insulation products to protect your roof, walls, and floor while insulating!

image image image

Technical Information

Technical Information

SELECT VARIABLE

THERMAL PERFORMANCE
PRODUCT DIMENSIONS
FIRE PERFORMANCE
ADDITIONAL INFO
PRODUCT COMPOSITION
Specification Value
Product SF19FR
Core Performance 1.31 R Value
Roof Performance* 2.22 R Value
Wall Performance* 2.64 R Value
Floor Performance* 3.97 R Value
Emittance 0.05

*Core value + 2 air spaces / EN 16012

Specification Value
Thickness 40mm
Length 10m
Width 1.5m
Coverage 15m²
Weight 13kg

*Core value + 2 air spaces / EN 16012

Specification Value
Reaction To Fire (Euroclass) Class E
Fire Propagation (BS476-6) Class 0
Spread Of Flame (BS476-7) Class 1

*Core value + 2 air spaces / EN 16012

Specification Value
Water Vapour Resistance 1200MNs/g
Resistance To Water Penetration W1
Tensile Properties (Length) 480N/50mm
Tensile Properties (Width) 415N/50mm
Resistance to Tearing (Length) 428N
Resistance to Tearing (Width) 453N
Elongation (Length) 4%
Elongation (Width) 3%
Flexibility at Low Temp. -40°C

*Core value + 2 air spaces / EN 16012

Specification Value
Glass Fibre Reinforced Heavy Laminated Aluminium Foil 2
Aluminium Coated Reflective Foil PET Layers 4
Loft Quilt 80g/sqm Layers 5
High Density E Glass Fibrematte 0
Total Layers 11

*Core value + 2 air spaces / EN 16012
